The Schneider A9F77240 is a miniature circuit breaker (MCB) designed for residential and commercial electrical installations. Here’s a detailed description:

Schneider A9F77240 Miniature Circuit Breaker

1. Application:

• The A9F77240 MCB is used for protecting electrical circuits against overloads and short circuits in various applications, including residential, commercial, and industrial settings.

2. Specifications:

• Rated Current: 40A
• Poles: 1P (Single Pole)
• Breaking Capacity: 10kA
• Voltage Rating: 240V AC
• Tripping Characteristics: Type C (suitable for general applications with moderate inrush currents)

3. Features:

• Compact Design: The miniature size allows for installation in limited space electrical panels.
• DIN Rail Mounting: Compatible with standard DIN rail mounting, facilitating easy installation and maintenance.
• Quick Tripping: Provides rapid disconnection of faulty circuits to prevent damage to electrical equipment and enhance safety.
• Compliance: Meets international standards for electrical protection devices, ensuring reliability and performance.

4. Usage:

• The A9F77240 is commonly used in distribution boards, consumer units, and switchboards to protect circuits feeding lighting, power sockets, and other electrical loads.

5. Safety Standards:

• Designed and tested to comply with IEC (International Electrotechnical Commission) standards, ensuring safety and reliability in electrical installations.

6. Applications:

• Suitable for both residential and commercial applications where reliable circuit protection is essential.

7. Manufacturer:

• Manufactured by Schneider Electric, a global leader in energy management and automation, known for high-quality electrical products.

8. Additional Information:

• For detailed technical specifications, installation guidelines, and compatibility with specific electrical systems, refer to Schneider Electric’s product documentation or consult with a qualified electrician.

The Schneider A9F77240 MCB provides essential circuit protection against overcurrents and short circuits, making it a vital component in modern electrical installations.
