Schneider GM32D4N2504BEE | Manual transfer switch, GoPact MTS 315, 4 poles, 250A, 415VAC 50/60Hz, extended rotary handle, open transition

1. Technical Specifications

• Product Code: GM32D4N2504BEE

• Product Type: Manual Transfer Switch

• Series: GoPact MTS 315

• Rated Current: 250 Amps

• Number of Poles: 4 Poles (3 Phase + Neutral)

• Rated Operational Voltage: 415 VAC

• Frequency: 50/60 Hz

• Switching Mechanism: Open Transition (Break-before-make)

• Operation Mode: Manual, with extended rotary handle

• Mounting Type: Panel-mounted or inside switchgear enclosures

• Application: Manual switching between two power sources (e.g., utility and generator)

2. Key Features

1. 250A Rated Capacity for Heavy-Duty Loads
   Designed to handle higher electrical demands safely and efficiently in industrial, commercial, or infrastructure applications.

2. Open Transition for Safe Source Separation
   Prevents overlapping of two power sources, reducing risk of backfeed, electrical faults, or equipment damage.

3. Four-Pole Design
   Allows disconnection of all phases and the neutral conductor, offering full circuit isolation and enhanced safety.

4. Extended Rotary Handle
   Provides convenient and secure external manual operation—ideal for emergency scenarios or operator-controlled switching.

5. Durable Industrial-Grade Construction
   Built to withstand harsh environments, repeated manual operations, and long-term use under load.

3. Typical Applications

• Industrial Manufacturing Plants
  Enables seamless manual source switching to ensure continuity of operations during power outages.

• Hospitals and Healthcare Facilities
  Provides dependable backup control in environments where uptime is critical to patient safety.

• Commercial Towers and Business Complexes
  Allows building management to maintain essential services by switching between grid and generator power.

• Educational Institutions and Government Buildings
  Ensures energy continuity for critical systems in public or administrative facilities.

• Residential Compounds with Central Generator Systems
  Offers an efficient manual solution for load transfer between utility and standby power.
