Schneider LV510300 | circuit breaker EasyPact CVS100B, 25 kA at 415 VAC, 16 A rating thermal magnetic TM-D trip unit, 3P 3d



Technical Specifications

• Model: Schneider LV510300 | EasyPact CVS100B
• Rated Current: 16A
• Breaking Capacity: 25 kA at 415V AC
• Poles: 3P (Three-Pole)
• Trip Unit Type: Thermal-Magnetic TM-D
• Voltage Rating: 415V AC
• Mounting Type: Fixed
• Protection Type: Overload & Short Circuit
• Standard Compliance: IEC 60947-2
• Operating Temperature: -25°C to 70°C

Key Features

1. Reliable Protection Mechanism
   • Thermal-Magnetic TM-D Trip Unit ensures fast and precise disconnection in case of overloads or short circuits.
   • 25 kA breaking capacity at 415V AC offers robust protection for demanding electrical environments.
2. High Durability & Performance
   • Designed to withstand harsh industrial and commercial conditions.
   • Ensures long-term reliability and reduced maintenance needs.
3. Versatile & Easy Installation
   • Three-pole (3P) configuration for balanced three-phase power distribution.
   • Compact design allows seamless integration into electrical panels.
4. Compliance with International Standards
   • Certified under IEC 60947-2, ensuring adherence to global safety and performance regulations.

Applications

The Schneider LV510300 | EasyPact CVS100B circuit breaker is widely used in various sectors, including:

Industrial Facilities – Protecting heavy machinery and electrical panels.
Commercial Buildings – Ensuring safe power distribution in offices and retail spaces.
Residential Installations – Providing enhanced protection for electrical circuits.
Power Distribution Systems – Acting as a key component in electrical switchgear.
